AGM Secutor LRF 50-640 Thermal Scope 2.5-20x50mm

The AGM Secutor LRF is a compact thermal imaging clip-on designed to convert day optics into a thermal sighting device without special tools. It combines a high-sensitivity 12 µm thermal detector and a 640 × 512 sensor with a 1024 × 768 OLED display to provide clear imagery in low-light and obscured conditions. The unit includes a built-in laser rangefinder, multiple reticle options, onboard recording, and compatibility with external power for extended use. Ergonomic controls, standby mode, and IP67 ingress protection support reliable field operation.

Key Specifications

• The magnification range is 2.5–20x for flexible engagement distances.
• The objective lens measures 50 mm to optimize light gathering.
• The thermal sensor resolution is 640 × 512 with a 50 Hz refresh rate.
• The detector uses a 12 μm VOx uncooled focal plane array.
• The built-in laser rangefinder is class 1 eye-safe with a listed range of approximately 1000 m and ±4-yard accuracy as provided.
• Onboard storage is 16 GB eMMC for video and image capture.
• Power is provided by CR123A batteries with a quoted run time of 6+ hrs, and external 5V power support.
• Field of view is 8.80 × 7 degrees for the listed optics package.
• The unit is rated IP67 for dust-tight and waterproof performance.
• The housing is specified to withstand recoil up to 1000 G.

The Secutor LRF delivers a practical balance of detection capability and onboard features for users who need thermal imaging with rangefinding and recording in one package. Its compact clip-on form factor, digital zoom steps, selectable palettes, and multiple reticle options make it suitable for observation, predator management, or professional field use where reliable thermal imaging and distance measurement are required.
